OCL-120/200双伺服连续式酱料/液体全自动包装机 Double servo continuous sauce/liquid automatic packaging machine
全国服务热线:
159-1595-6886(微信同号)全国服务热线:
159-1595-6886(微信同号)用途:Application
包装各种酱类、液体、膏体、粉末、颗粒等物品。
Packing different kinds ofjam,liquid,cream powder, granule material.
特点:Characteristics
OCL型智能连续式包装机可针对粉末,颗粒,液体,膏体等不同物料实现三边封口或四边封口的包装。采用了先进的工业计算机控制系统,学习日本机型设计,可方便的等不同袋子长度,包装速度。包装计量调整变化。该机有三组热辊筒。封口采用棋盘纹配合防漏线。可实现单双列连续包装要求。另外该机还装备有方便开袋的易撕切口装置。
OCL type automatic continuous packing roachire was designed for packing materiallike: powder, granule, liquid,paste etc to achieve different seal requirement like 314 sides seal.Adopt advanced industrial computer control system and learn from the Japan technology. it is easy to adjust the bag length, packing speed.filling rate. This machine has three sets of roller sealer. Sealing effect adopt black plaid with Leakproof line. Singleldouble line packing bag is available Also with the easy tear device.
技术参数:Technical Parameter
袋型 Sachet type | 三/四边封3/4 sides seal | |
袋子尺寸范围 | 最大尺寸Max.Size | 200mm(W)x240mm(L) |
Sachet size range | 最小尺寸Min.Size | 40mm(W)x60mm(L) |
计量范围 Filling Rate | 60-400m1(custamized) | |
包装速度 Packfng Speed | 30-80 bagslmin | |
主机功率 Electricity Pawer | 5.5kw | |
电源要求 Working Voltage | 380V/50Hz | |
卷膜直径 Film Roll Diameter | 450 mm | |
最大膜宽 Max Film Width | 400mm | |
机器尺寸 Machine dimension | 1400x1000x1800mm(LX-120) | |
1500x1100x2300mm(LX-120) | ||
机器重量 Machine Weieht | 550-650kg |
